Nail-Holding Hammer with Fold-Out Drivers

The problem

A hammer is one of the most common household tools, and its weak point is the start of every job: you hold the nail between finger and thumb for the first few taps. A missed blow lands on your fingers. A basic hammer is also only a hammer - for the screw next to the nail, you go and find a screwdriver.

The solution

The patent adds three simple features to an ordinary hammer:

1. A T-shaped slot (4) on the top face of the head (2). The nail is laid in the slot with its point sticking out past the end, so the hammer itself holds it for the first blow.
2. A wedge-shaped peen (3), formed in one piece with the head, on the opposite end.
3. A groove that runs the full length of the handle (1), with a pivot pin at the far end carrying a flat screwdriver bit (5), a star (Phillips-type) screwdriver bit (6) and a blade (7). Each is shorter than the groove, so all three fold away inside the handle.

Who it is for

• Tool brands and importers looking for a differentiated household hammer or a gift-set item.
• Home-improvement and hardware retailers selling “first toolkit” and apartment tool products.
• Promotional and kit suppliers - moving-day kits, car kits, dorm kits.

How it works

The main parts

Starting a nail without holding it

1. Lay the nail in the T-slot (4) on top of the head - the head of the nail sits in the cross-bar of the T, the shank lies in the long slot, and the point sticks out past the end of the head.
2. Press the point against the wall or board where it should go.
3. Push or tap so the nail is set in the surface - your fingers never hold the nail.
4. Turn the hammer and drive the nail home with the striking face as usual.

Using the fold-out tools

1. Swing the flat driver (5), star driver (6) or blade (7) out of the handle groove on its pivot.
2. Use the handle as the grip.
3. Fold the tool back into the groove when finished.

The patent also lists LED lights on the handle as an option (claim 5); a plain version without electronics is equally possible.

Applications

Home and apartment toolkits

Hanging pictures, assembling flat-pack furniture, tightening loose screws - one tool covers the common jobs.

Gift and starter tool sets

The nail-holding slot is easy to show on packaging and in a short video, which suits gift and first-home sets.

Craft, hobby and DIY projects

Small nails and tacks that are hard to hold by hand: picture frames, birdhouses, trim.

Car, boat and RV kits

A compact hammer that also replaces two screwdrivers and a knife in a small emergency kit.

Promotional products

Logo on the handle or head for hardware stores, real-estate agents and builders.

Where it is less suitable

• Framing and heavy carpentry - professionals use heavier framing hammers and nail guns.
• Fine screws and precision work - fold-out bits are a convenience, not a replacement for a full driver set.
