Garden & Outdoor Patents

Garden and outdoor products from Chinese patents - a wire-mesh tree root guard against rodents and a two-in-one umbrella with a child-size umbrella stored in its shaft.

18 patents in this category

2-in-1 Parent & Child Umbrella - patent drawing

Garden & Outdoor

2-in-1 Parent & Child Umbrella

Full-size umbrella with a nested smaller umbrella on top - a rotating decorative layer that detaches into a kid-size umbrella.

Patent CN205611962U

Wire-Mesh Tree Root & Trunk Guard Against Rodents - patent drawing

Garden & Outdoor

Wire-Mesh Tree Root & Trunk Guard Against Rodents

Three-part wire-mesh guard that protects the roots and lower trunk of young trees from burrowing and gnawing animals.

Patent CN206808261U

Adjustable-Angle Tree Support Prop - patent drawing

Garden & Outdoor

Adjustable-Angle Tree Support Prop

Tree prop with a pinned base, angle-locking hinge, twist-adjust tube and a locking trunk ring.

Patent CN208370491U

Self-Renewing Glue-Roller Mosquito Trap - patent drawing

Garden & Outdoor

Self-Renewing Glue-Roller Mosquito Trap

UV insect trap with a glue roller that re-coats itself and scrapes the catch into a tray - no glue boards.

Patent CN217038569U

Cam-Lock Telescopic Pole for Garden Power Tools - patent drawing

Garden & Outdoor

Cam-Lock Telescopic Pole for Garden Power Tools

Telescopic pole for garden power tools with cam-lever locks and a spring-button, tear-drop head socket.

Patent CN205812889U

Mosquito Fan That Listens for Mosquitoes Before It Sprays - patent drawing

Garden & Outdoor

Mosquito Fan That Listens for Mosquitoes Before It Sprays

Fan with a scanning microphone dish that mists repellent only when it hears mosquitoes.

Patent CN208708542U

Flat Pressure-Compensating Drip Emitter with Built-In Filter Chamber for Drip Tape - patent drawing

Garden & Outdoor

Flat Pressure-Compensating Drip Emitter with Built-In Filter Chamber for Drip Tape

Flat inline dripper for drip tape: filter chamber, labyrinth paths and a diaphragm for even flow.

Patent CN205922296U

Screw-In Bug Zapper Bulb with Color LEDs and a Built-In Music Player - patent drawing

Garden & Outdoor

Screw-In Bug Zapper Bulb with Color LEDs and a Built-In Music Player

Screw-in lantern bulb: UV bug zapper behind a double grid, color LEDs and a music player.

Patent CN206831443U

Adjustable-Angle LED Mushroom Cultivation Rack - patent drawing

Garden & Outdoor

Adjustable-Angle LED Mushroom Cultivation Rack

Multi-tier mushroom rack: shelves tilt in opposite directions via one motor; LEDs fill gaps.

Patent CN207040403U

Vortex Airflow Insect Trap with Filter Isolation - patent drawing

Garden & Outdoor

Vortex Airflow Insect Trap with Filter Isolation

Fan-powered insect trap using a swirling vortex to dehydrate bugs without blade contact.

Patent CN215602781U

Vertical Crop Cultivation System with Nutrient, Light, Air and Audio Control - patent drawing

Garden & Plants

Vertical Crop Cultivation System with Nutrient, Light, Air and Audio Control

Layered indoor farming system with underground nutrient tanks, lighting, bubble air control and audio.

Patent CN208691875U

Inner-Closing Pedal Mousetrap with Dual Doors and Linkage Mechanism - patent drawing

Pest Control

Inner-Closing Pedal Mousetrap with Dual Doors and Linkage Mechanism

Live-catch mousetrap with inward-closing dual doors linked by cables and a pedal trigger.

Patent CN113498770B

Sun Umbrella with Built-In Fan and Magnetic Clamp Shell - product render

Garden & Outdoor

Sun Umbrella with Built-In Fan and Magnetic Clamp Shell

Sun umbrella with a battery-powered fan shell and magnetic quick-release clamp.

Patent CN108903170B

Globe-Shaped Fish Tank and Flowerpot Device with Auto-Watering - product render

Garden & Outdoor

Globe-Shaped Fish Tank and Flowerpot Device with Auto-Watering

Globe-shaped fish tank and planter with auto-watering via a humidity sensor and solenoid valve.

Patent CN206078239U

Conical Indoor Mosquito Trap with Light and Liquid Lure - product render

Garden & Outdoor

Conical Indoor Mosquito Trap with Light and Liquid Lure

Conical indoor mosquito trap using light and a liquid lure in a contained box.

Patent CN107836425B

Windproof Sunshade Umbrella with Rotating Overlapping Blades - product render

Garden & Outdoor

Windproof Sunshade Umbrella with Rotating Overlapping Blades

Sunshade umbrella with angled, overlapping blades that let wind spin the canopy.

Patent CN105815903B

Foldable Plant Growth Light with Central Power Box - product render

Garden & Plants

Foldable Plant Growth Light with Central Power Box

Foldable plant lamp with a sealed central beam housing the power distributor and dimmer.

Patent CN216307484U

Electric Garden Insect Trap with Attractant Dispenser and Auto-Cleaning Cylinder - product render

Pest Control

Electric Garden Insect Trap with Attractant Dispenser and Auto-Cleaning Cylinder

Garden insect trap with an electric lifting cylinder and attractant dispenser for automatic clearing.

Patent CN114731996B

About this category

Outdoor products are bought to solve a problem in the field: rodents eating the roots of young trees, or a family that needs two umbrellas but wants to carry one. The patents in this collection cover both - a three-part wire-mesh guard installed when planting, and a full-size umbrella with a small child umbrella that sits on top as a second canopy and pulls out when needed.

These patents were filed only in China. Our product pages explain how each design works, which customers buy it - orchards, nurseries, garden retailers, family-product brands - and what to test before stating protection periods or wind resistance on the package.

What to look for in this category: products that ship flat or compact, and durable materials for sun, rain and soil.

For patios and decks there is now a fan with a turning dish microphone that listens for the hum of mosquitoes and only mists repellent when it hears them, pausing when a person comes close.
